Architecture

ADORE Architecture data model (UML), click to enlarge:

Architecture

adore.api.schema.adore_schema.Architecture

Architecture

Represents an architecture instance, as derived from the architecture design space by taking architecture choices. Can be either derived manually, or from a design problem (in this case the design problem is referenced).

constraints

constraints: Optional[List[ArchConstraint]] = constraints

context

context: ArchSystemContext = context

decisions

decisions: List[ArchDecision] = decisions

design_problem_id

design_problem_id: Optional[int] = design_problem_id

design_vars

design_vars: Optional[List[Union[ArchDiscreteDesignVar, ArchContinuousDesignVar]]] = design_vars

eval_duration_sec

eval_duration_sec: Optional[float] = eval_duration_sec

Duration of architecture evaluation (seconds)

eval_time_end

eval_time_end: Optional[str] = eval_time_end

End of architecture evaluation (ISO8601 timestamp)

eval_time_start

eval_time_start: Optional[str] = eval_time_start

Start of architecture evaluation (ISO8601 timestamp)

feasible

feasible: bool = feasible

An architecture is valid if all functions are fulfilled and all port connections have been made according to their connection specifications.

final

final: bool = final

An architecture is final if there all choices have been taken and all design variables have been set.

id

id: int = id

name

name: str = name

notes

notes: Optional[str] = notes

objectives

objectives: Optional[List[ArchObjective]] = objectives

perf_evaluated

perf_evaluated: bool = perf_evaluated

Whether or not the performance of this architecture has been evaluated.

perf_feasible

perf_feasible: Optional[bool] = perf_feasible

Whether or not the evaluated performance is feasible when taking optimization constraints into account. If undefined if the performance has not been evaluated.

ref

ref: Optional[str] = ref

Optional reference, used for linking to external interfaces.

system

system: ArchSystem = system

adore.api.schema.adore_schema.ArchSystem

ArchSystem

A architecture system as derived from a design space system object.

components

components: List[ArchComponent] = components

concepts

concepts: List[ArchConcept] = concepts

decompositions

decompositions: List[ArchDecomposition] = decompositions

display

display: Optional[List[DisplayProperties]] = display

edges

edges: Optional[List[EdgeProperties]] = edges

element_id

element_id: int = element_id

Reference to the design space element that forms the basis of this architecture element.

functions

functions: List[ArchFunction] = functions

id

id: int = id

index

index: int = index

The index (0-based) of the system instance.

multi_fulfillments

multi_fulfillments: List[ArchMultiFulfillment] = multi_fulfillments

name

name: str = name

non_fulfillments

non_fulfillments: List[ArchNonFulfillment] = non_fulfillments

notes

notes: Optional[str] = notes

ports

ports: List[ArchPort] = ports

qois

qois: List[ArchQOI] = qois

ref

ref: Optional[str] = ref

Optional reference, used for linking to external interfaces.

systems

systems: List[ArchSystem] = systems

adore.api.schema.adore_schema.ArchSystemContext

ArchSystemContext

The architecture system context, or external environment, derived from the design space system context.

components

components: List[ArchComponent] = components

concepts

concepts: List[ArchConcept] = concepts

decompositions

decompositions: List[ArchDecomposition] = decompositions

display

display: Optional[List[DisplayProperties]] = display

edges

edges: Optional[List[EdgeProperties]] = edges

element_id

element_id: int = element_id

Reference to the design space element that forms the basis of this architecture element.

functions

functions: List[ArchFunction] = functions

id

id: int = id

multi_fulfillments

multi_fulfillments: List[ArchMultiFulfillment] = multi_fulfillments

name

name: str = name

non_fulfillments

non_fulfillments: List[ArchNonFulfillment] = non_fulfillments

notes

notes: Optional[str] = notes

ports

ports: List[ArchPort] = ports

qois

qois: List[ArchQOI] = qois

ref

ref: Optional[str] = ref

Optional reference, used for linking to external interfaces.

System Elements

adore.api.schema.adore_schema.ArchFunction

ArchFunction

A function instance, derived from a design space function.

boundary_function

boundary_function: bool = boundary_function

Whether the function is a boundary function or not.

element_id

element_id: int = element_id

Reference to the design space element that forms the basis of this architecture element.

id

id: int = id

name

name: str = name

notes

notes: Optional[str] = notes

qois

qois: List[ArchQOI] = qois

QOIs assigned to the architecture function.

ref

ref: Optional[str] = ref

Optional reference, used for linking to external interfaces.

type

type: FunctionType = type

adore.api.schema.adore_schema.ArchComponent

ArchComponent

A component instance, derived from a design space component.

display

display: Optional[List[DisplayProperties]] = display

edges

edges: Optional[List[EdgeProperties]] = edges

element_id

element_id: int = element_id

Reference to the design space element that forms the basis of this architecture element.

fulfilled_arch_function_ids

fulfilled_arch_function_ids: List[int] = fulfilled_arch_function_ids

id

id: int = id

instances

instances: List[ArchComponentInstance] = instances

The component instances.

name

name: str = name

needed_arch_function_ids

needed_arch_function_ids: List[int] = needed_arch_function_ids

notes

notes: Optional[str] = notes

qois

qois: List[ArchQOI] = qois

QOIs assigned to the architecture component.

ref

ref: Optional[str] = ref

Optional reference, used for linking to external interfaces.

adore.api.schema.adore_schema.ArchComponentInstance

ArchComponentInstance

A component instance linked to an architecture component.

attributes

attributes: List[ArchAttribute] = attributes

Attributes assigned to this component instance. Note that component attributes (as opposed to component instance attributes) are also assigned to the component instances.

element_id

element_id: int = element_id

Reference to the design space element that forms the basis of this architecture element.

id

id: int = id

index

index: int = index

The index (0-based) of the component instance.

input_ports

input_ports: List[ArchPortInstance] = input_ports

The input port instances of this component instance.

name

name: str = name

notes

notes: Optional[str] = notes

output_ports

output_ports: List[ArchPortInstance] = output_ports

The output port instances of this component instance.

qois

qois: List[ArchQOI] = qois

QOIs assigned to the architecture component instance.

ref

ref: Optional[str] = ref

Optional reference, used for linking to external interfaces.

adore.api.schema.adore_schema.ArchQOI

ArchQOI

An architecture Quantity Of Interest, derived from a design space QOI.

element_id

element_id: int = element_id

Reference to the design space element that forms the basis of this architecture element.

evaluated

evaluated: bool = evaluated

feasible

feasible: Optional[bool] = feasible

id

id: int = id

name

name: str = name

notes

notes: Optional[str] = notes

option_index

option_index: Optional[int] = option_index

ref

ref: Optional[str] = ref

Optional reference, used for linking to external interfaces.

type

type: QOIType = type

units

units: Optional[str] = units

value

value: Optional[float] = value

value_str

value_str: Optional[str] = value_str

adore.api.schema.adore_schema.ArchAttribute

ArchAttribute

An architecture component attribute, derived from a design space component attribute. Its assigned values are defined as primitives rather than as attribute value objects.

element_id

element_id: int = element_id

Reference to the design space element that forms the basis of this architecture element.

id

id: int = id

name

name: str = name

notes

notes: Optional[str] = notes

ref

ref: Optional[str] = ref

Optional reference, used for linking to external interfaces.

values

values: List[str] = values

adore.api.schema.adore_schema.ArchPortInstance

ArchPortInstance

A component port instance, derived from a design space port connection. Assigned to either the input or output ports of a component instances.

arch_port_id

arch_port_id: int = arch_port_id

element_id

element_id: int = element_id

Reference to the design space element that forms the basis of this architecture element.

id

id: int = id

index

index: int = index

The index (0-based) of the port connection instance.

name

name: str = name

notes

notes: Optional[str] = notes

ref

ref: Optional[str] = ref

Optional reference, used for linking to external interfaces.

target_ids

target_ids: List[int] = target_ids

The port instance IDs to which this port is connected.

adore.api.schema.adore_schema.ArchPort

ArchPort

A port instance, derived from a design space port.

element_id

element_id: int = element_id

Reference to the design space element that forms the basis of this architecture element.

id

id: int = id

name

name: str = name

notes

notes: Optional[str] = notes

ref

ref: Optional[str] = ref

Optional reference, used for linking to external interfaces.

adore.api.schema.adore_schema.ArchConcept

ArchConcept

A concept instance, derived from a design space concept.

element_id

element_id: int = element_id

Reference to the design space element that forms the basis of this architecture element.

id

id: int = id

name

name: str = name

neutral_arch_function_id

neutral_arch_function_id: int = neutral_arch_function_id

notes

notes: Optional[str] = notes

ref

ref: Optional[str] = ref

Optional reference, used for linking to external interfaces.

specific_arch_function_id

specific_arch_function_id: Optional[int] = specific_arch_function_id

adore.api.schema.adore_schema.ArchDecomposition

ArchDecomposition

A decomposition instance, derived from a design space decomposition.

element_id

element_id: int = element_id

Reference to the design space element that forms the basis of this architecture element.

emerged_arch_function_id

emerged_arch_function_id: int = emerged_arch_function_id

id

id: int = id

name

name: str = name

notes

notes: Optional[str] = notes

ref

ref: Optional[str] = ref

Optional reference, used for linking to external interfaces.

zoomed_arch_function_ids

zoomed_arch_function_ids: List[int] = zoomed_arch_function_ids

adore.api.schema.adore_schema.ArchNonFulfillment

ArchNonFulfillment

A non-fulfillment instance, derived from a design space non-fulfillment.

arch_function_ids

arch_function_ids: List[int] = arch_function_ids

element_id

element_id: int = element_id

Reference to the design space element that forms the basis of this architecture element.

id

id: int = id

name

name: str = name

notes

notes: Optional[str] = notes

ref

ref: Optional[str] = ref

Optional reference, used for linking to external interfaces.

adore.api.schema.adore_schema.ArchMultiFulfillment

ArchMultiFulfillment

A multi-fulfillment instance, derived from a design space multi-fulfillment.

arch_function_ids

arch_function_ids: List[int] = arch_function_ids

element_id

element_id: int = element_id

Reference to the design space element that forms the basis of this architecture element.

id

id: int = id

name

name: str = name

notes

notes: Optional[str] = notes

ref

ref: Optional[str] = ref

Optional reference, used for linking to external interfaces.

Design Problem Elements

adore.api.schema.adore_schema.ArchObjective

ArchObjective

An instance of an objective used in the containing architecture instance. The value is set if the performance has been evaluated.

arch_qoi_id

arch_qoi_id: int = arch_qoi_id

id

id: int = id

maximize

maximize: bool = maximize

name

name: str = name

notes

notes: Optional[str] = notes

objective_id

objective_id: int = objective_id

ref

ref: Optional[str] = ref

Optional reference, used for linking to external interfaces.

value

value: Optional[float] = value

adore.api.schema.adore_schema.ArchConstraint

ArchConstraint

An instance of a constraint used in the containing architecture instance. The value is set if the performance has been evaluated.

arch_qoi_id

arch_qoi_id: Optional[int] = arch_qoi_id

constraint_id

constraint_id: int = constraint_id

id

id: int = id

name

name: str = name

notes

notes: Optional[str] = notes

pos_feasible

pos_feasible: bool = pos_feasible

ref

ref: Optional[str] = ref

Optional reference, used for linking to external interfaces.

ref_value

ref_value: float = ref_value

value

value: Optional[float] = value

adore.api.schema.adore_schema.ArchDiscreteDesignVar

ArchDiscreteDesignVar

An instance of a discrete design variable used in the containing architecture instance. The option index is the one used for deriving this architecture and evaluating its performance.

active

active: bool = active

arch_decision_id

arch_decision_id: Optional[int] = arch_decision_id

arch_qoi_id

arch_qoi_id: Optional[int] = arch_qoi_id

design_var_id

design_var_id: int = design_var_id

fixed

fixed: bool = fixed

id

id: int = id

name

name: str = name

notes

notes: Optional[str] = notes

option_index

option_index: int = option_index

options

options: List[str] = options

ref

ref: Optional[str] = ref

Optional reference, used for linking to external interfaces.

adore.api.schema.adore_schema.ArchContinuousDesignVar

ArchContinuousDesignVar

An instance of a continuous design variable used in the containing architecture instance. The value is the one used for deriving this architecture and evaluating its performance.

active

active: bool = active

arch_decision_id

arch_decision_id: Optional[int] = arch_decision_id

arch_qoi_id

arch_qoi_id: Optional[int] = arch_qoi_id

bounds

bounds: List[float] = bounds

design_var_id

design_var_id: int = design_var_id

fixed

fixed: bool = fixed

id

id: int = id

name

name: str = name

notes

notes: Optional[str] = notes

ref

ref: Optional[str] = ref

Optional reference, used for linking to external interfaces.

value

value: float = value

Types

adore.api.schema.adore_schema_defs.ArchBaseSystem

ArchBaseSystem = Union[ArchSystem, ArchSystemContext]

adore.api.schema.adore_schema_defs.ArchElement

ArchElement = Union[ArchBaseSystem, ArchFunction, ArchConcept, ArchDecomposition, ArchComponent, ArchComponentInstance, ArchQOI, ArchPortInstance, ArchPort, ArchAttribute, ArchNonFulfillment, ArchMultiFulfillment]

adore.api.schema.adore_schema_defs.ArchDesignVar

ArchDesignVar = Union[ArchDiscreteDesignVar, ArchContinuousDesignVar]
